Controlling White Space Characters

This section provides a tutorial example on how to control white space characters in the content of 'block' formatting object. By default, white space characters are collapsed and linefeed chacters are converted to space.

XSL-FO 1.1 offers a number of attributes on "block" formatting objects to control how white space characters in the content should be handled:

Here is my tutorial example, White-Space-Character-Handling.fo, that has 3 "block" formatting objects with different white space character settings:

<?xml version="1.1" encoding="utf-8"?>
<!-- White-Space-Character-Handling.fo
 - Copyright (c) 2006 HerongYang.com. All Rights Reserved.
-->
<fo:root xmlns:fo="http://www.w3.org/1999/XSL/Format">
 <fo:layout-master-set>
  <fo:simple-page-master master-name="page"
   margin="0.1in" page-height="4.4in" page-width="3.4in">
   <fo:region-body region-name="body"/>
  </fo:simple-page-master>
 </fo:layout-master-set>
 <fo:page-sequence master-reference="page">
  <fo:flow flow-name="body">
<fo:block background-color="#ffddff" font-family="monospace"
 font-size="8pt"
> _____________________
|  _________________  |
| |                 | |
| |      0   0      | |
| |        -        | |
| |      \___/      | |
| |_________________| |
|_____________________|
     _|_________|_
    /             \
   -----------------
</fo:block>
<fo:block background-color="#dddddd" font-family="monospace"
 font-size="8pt" linefeed-treatment="preserve"
> _____________________
|  _________________  |
| |                 | |
| |      0   0      | |
| |        -        | |
| |      \___/      | |
| |_________________| |
|_____________________|
     _|_________|_
    /             \
   -----------------
</fo:block>
<fo:block background-color="#ffdddd" font-family="monospace"
 font-size="8pt" linefeed-treatment="preserve"
 white-space-collapse="false" white-space-treatment="preserve"
> _____________________
|  _________________  |
| |                 | |
| |      0   0      | |
| |        -        | |
| |      \___/      | |
| |_________________| |
|_____________________|
     _|_________|_
    /             \
   -----------------
</fo:block>
  </fo:flow>
 </fo:page-sequence>
</fo:root>

When you process the above sample XSL-FO document to a PDF file and open it, you will see a big block area that contains some text and two child blocks:

White Space Character Handling
White Space Character Handling
