"Body" Region Margin and "Side" Region Extent

This section provides tutorial example to demonstrate how the region-before extent overlaps with the top margin of the region-body. It can also be extended into and hidden behind the content area of the region-body.

One of common issues of using a "side" region in a simple-page-master layout is to know how to control its extent="..." attribute. Here are two rules that may be helpful to you in designing "side" regions:

1. The location and size of the "body" region are independent of "side" regions. In other words, the "region-body" content area size is always equal to the page size after removing the layout margin and its own margin.

For example, if a simple-page-master layout has a 8.5in by 11in page size, and a 0.5in layout margin, the region-body with a 1.2in margin will result a region-body content area of 8.5 - 2*0.5 - 2*1.2 = 5.1 inch wide and 11 - 2*0.5 - 2*1.2 = 7.6 inch high.

2. If a "side" region is added, its width is determined by its extent="..." attribute. Its outer side is aligned to the outer side of the margin area of the "body" region.

In other words, a "side" region is always overlapped with the margin portion of the "body" region. If the "side" region is too wide, it will be extended into and "hidden" behind the content portion of the "body" region.

For example, if the region-body has a 1.2in margin, a region-before with a 1.5in extent will overlap the region-body top margin and a 0.3in portion will be "hidden" behind the region-body content area.

To demonstrate these rules, I wrote the following XSL-FO document: region-before-Extented-Too-Wide.fo.

<?xml version="1.1" encoding="utf-8"?>
<!-- region-before-Extented-Too-Wide.fo
 - Copyright (c) 2006 HerongYang.com. All Rights Reserved.
-->
<fo:root xmlns:fo="http://www.w3.org/1999/XSL/Format">
 <fo:layout-master-set>
  <fo:simple-page-master master-name="my_page" margin="0.5in"
   page-height="11in" page-width="8.5in"
   reference-orientation="0" writing-mode="lr-tb">
   <fo:region-body region-name="my_body" background-color="#eeeeee"
   margin="1.2in" reference-orientation="0" writing-mode="lr-tb"/>
   <fo:region-before region-name="my_header" background-color="#ffeeee"
   extent="1.5in" reference-orientation="0" writing-mode="lr-tb"/>
  </fo:simple-page-master>
 </fo:layout-master-set>
 <fo:page-sequence master-reference="my_page">
  <fo:static-content flow-name="my_header">
   <fo:block>&lt;region-before extent="1.5in" ...&gt;</fo:block>
  </fo:static-content>
  <fo:flow flow-name="my_body">
   <fo:block>&lt;region-body margin="1.2in" ...&gt;</fo:block>
  </fo:flow>
 </fo:page-sequence>
</fo:root>

The quickest way to see the output of this example XSL-FO document to process it with Apache FOP tool on the AWT window:

herong> fop -fo region-before-Extented-Too-Wide.fo -awt

You should see a page displaying the "before" region in pink and the "body" region in gray as shown below:

region-body Margin and region-before Extent
region-body Margin and region-before Extent

Note that the "before" region is extended to cover the entire top margin of the "body" region and overlapped partially with the content area of the "body" region.
